1. Classic relationships

Relationship between geometric spring dimensions :
- for springs whose end coils are joined and ground over three-quarters of their length, we have : $\begin{array}{l} l_{0} = n_{u} h_{0} + d \\ l_{b} = n_{t} d \end{array}$
- when this spring is compressed with contiguous coils, the magnification of the average diameter is : $D^{'} - D = \frac{(h_{0} + d) e_{0}}{6 D}$
  ...
