3. Measurement of 1 dB compression point and 3rd-order intercept point

These parameters characterize the linearity of components and are essential in the design of communication systems.

3.1 Compression point at 1 dB

For a non-linear system, the output voltage V s (t ) of a system can be written in a general way, as a function of its input V e (t ) :

Vst=aVet+bVe2t+cVe3t+…
